RIG

Short Description:

Type Rated Power(W) Dimension(mm) GHZ VSWR Heating Panel Porcelain Basal Body Thickness Leading-out Terminal Hole Diameter A ±0.2 B ±0.2 C ±0.2 E ±0.2 F ±0.2 G ±0.2 H max J ±0.2 K ±0.02 L ±0.5 ∅ RIG22 10 13 4 9 0.5 4 1 2.5 1 0.15 3 2.1 DC~4 1.2 RIG22B 20 8 14 1 10 1 3.5 2 0.1 6 2.8 DC~0.5 1.2 RIG22C 12.7 ...

FOB Price: US $0.01 - 99/ Piece

Min.Order Quantity: 1000 Pieces for Trimming Pot; 100 Pieces for Wire-wound Pot; and etc.

Supply Ability: 100000000 Pieces per Month

Production Time: 5-10 workdays for regular orders; 1-5 workdays for samples order.

Port: Shenzhen, Shanghai, Ningbo, Guangzhou, Chengdu and etc

Payment Terms: Western Union, Visa/Master Card, T/T, Paypal, e-checking and etc

Services: ODM, OEM

Send email to us Download as PDF

Product Detail

Product Tags

Type	Rated Power(W)	Dimension(mm)											GHZ	VSWR
		Heating Panel				Porcelain Basal Body		Thickness	Leading-out Terminal			Hole Diameter
		A ±0.2	B ±0.2	C ±0.2	E ±0.2	F ±0.2	G ±0.2	H max	J ±0.2	K ±0.02	L ±0.5	∅
RIG22	10	13	4	9	0.5	4	1	2.5	1	0.15	3	2.1	DC~4	1.2
RIG22B		20	8	14	1	10	1	3.5	2	0.1	6	2.8	DC~0.5	1.2
RIG22C		12.7	5	7.6	1.5	2.5	1	4	1	0.15	6	3	DC~3	1.2
RIG22D		20	8	14	1	7	1	3.5	2	0.1	6	2.8	DC~0.5	1.2
RIG22E		12.7	5	7.5	1.5	3	1	4	1	0.15	17	3.2	DC~3	1.2
RIG22	15	22	10	17	1	12	1	3.5	2.5	0.1	7	3	DC~0.5	1.2
RIG22B	15	22	10	17	1	8	1	3.5	2.5	0.1	7	3	DC~0.5	1.2
RIG22	20	14.5	5	10.5	0.5	6	1	3	1	0.15	4	2.2	DC~3	1.2
RIG22	30-60	20	6	14	1.5	6	1	4	1	0.15	4	3.2	DC~3	1.2
RIG22B		20	6	14	1.5	6.4	1	4	1	0.15	4	3.2	DC~3	1.2
RIG22C		21	8	15	2	10	1	4.5	2	0.1	5	3.2	DC~2	1.2
RIG22D		20	6	14	1.5	9	1	4	1	0.15	6	3.2	DC~3	1.2
RIG22	100	20	6	14	1.5	9	1	4	1	0.15	6	3.2	DC~3	1.2
RIG22B	100	25	10	19	3	10	1	5.5	1.5	0.15	6	3.5	DC~2.5	1.2
RIG22	150	25	6	19	1.5	12	1	4	3	0.1	7	3.5	DC~1	1.2
RIG22B		23	8	18	2	10	1.5	5	1.5	0.15	6	2.8	DC~2	1.2
RIG22C		25	10	19	3	10	1	5.5	1.5	0.15	6	3.5	DC~2	1.2
RIG22	200	25	1	19	3	10	1.5	6	2.5	0.1	7	3.5	DC~2	1.2
RIG22	250	25	10	18.5	3	12	1	5.5	3	0.1	7	3.5	DC~0.5	1.2
RIG22B		25	9.5	18.5	3	9.5	1.5	6	3	0.1	7	3.5	DC~1	1.2
RIG22C		25	10	18.5	3	12	4	8.5	3	0.1	7	3.5	DC~1.5	1.2
RIG22D		25	10	19	3	12	1	5.5	2.5	0.1	7	3.5	DC~0.5	1.2
RIG22E		25	12	19	3	10	1.5	5.5	2.5	0.1	7	3.5	DC~3	1.2
RIG22F		27	10	20	3	12	1.5	6	2.5	0.1	7	3.5	DC~3	1.2
RIG22	400	32	12.7	22	3	12.7	1.5	6	3	0.1	7	4	0.5	1.2
